8 P66 Series Electronic Fan Speed Controls Installation Instructions
Ordering Information
Table 3: P66 Control Specific Model Information
Product Code
Number
Operating Range
(psig)
Start Voltage
(% of Supply Voltage)
Capillary Length (in.)
Single Input Sensor Models
P66AAB-1
190/250 10 60
P66AAB-4
135/165
10
60
P66AAB-6
170/230
16
60
P66AAB-9
170/230
40
60
P66AAB-10
190/250
16
120
P66AAB-11
140/200
16
60
P66AAB-14
220/280
40
120
P66AAB-15
190/250
40
60
P66AAD-1*
160/220
25
60
P66ABB-21
+
220/280 16 120
P66AAB-34
320/410
40
60
Dual Input Sensor Models
P66BAB-1
190/250 10 60
P66BAB-3
170/230 16 60
P66BAB-4
190/250 16 120
P66BAB-5
190/250 40 60
P66BAD-1*
160/220 25 60
All models are rated for 208-240/277/480 volt; 60Hz except those with Product Code Numbers followed by an asterisk.
* 50 Hz Models
+
Models with NEMA 3R Enclosure
For further information on model specifications and options, please contact Johnson Controls Application
Engineering at 1-800-275-5676.

Penn P66AAB-1 Specifications

Pressure Ratings

control range (low pressure models)	80 to 200 psig (552 to 1379 kPa)
control range (medium pressure models)	140 to 350 psig (965 to 2413 kPa)
control range (high pressure models)	300 to 500 psig (2048 to 3447 kPa)
effective throttling range (low pressure models)	30 psi (207 kPa)
effective throttling range (medium pressure models)	60 psi (414 kPa)
effective throttling range (high pressure models)	90 psi (621 kPa)
maximum working pressure (low pressure models)	200 psig (1379 kPa)
maximum working pressure (medium pressure models)	350 psig (2413 kPa)
maximum working pressure (high pressure models)	500 psig (3447 kPa)
maximum overpressure (low pressure models)	250 psig (1724 kPa)
maximum overpressure (medium pressure models)	400 psig (2758 kPa)
maximum overpressure (high pressure models)	695 psig (4792 kPa)

Electrical Ratings

control voltage	24 VAC, 1VA
line voltage range	208 to 480 VAC
full load amperes (208 VAC)	8.0
full load amperes (240 VAC)	8.0
full load amperes (277 VAC)	6.9
full load amperes (480 VAC)	4.0
locked rotor amperes (208 VAC)	16.5
locked rotor amperes (240 VAC)	16.5
locked rotor amperes (277 VAC)	14.3
locked rotor amperes (480 VAC)	10.5

Operating Environment

maximum ambient temperature (208 VAC)	130°F/54°C
maximum ambient temperature (240 VAC)	130°F/54°C
maximum ambient temperature (277 VAC)	130°F/54°C
maximum ambient temperature (480 VAC)	150°F/66°C
minimum ambient storage temperature	-40°F/-40°C (at all Voltages)
ambient storage temperature range	-40°F/-40°C to 185°F/85°C
