Penn P66AAB-1 User Manual

P66 Series Electronic Fan Speed Controls Installation Instructions 9
Technical Specifications
Product
P66 Series Electronic Fan Speed Controls
Pressure Ratings
Low Pressure Models
Medium Pressure Models
High Pressure Models
Control Range
80 to 200 psig
(552 to 1379 kPa)
140 to 350 psig
(965 to 2413 kPa)
300 to 500 psig
(2048 to 3447 kPa)
Effective Throttling Range
30 psi (207 kPa)
60 psi (414 kPa)
90 psi (621 kPa)
Maximum Working
Pressure
200 psig (1379 kPa) 350 psig (2413 kPa) 500 psig (3447 kPa)
Maximum Overpressure
250 psig (1724 kPa)
400 psig (2758 kPa)
695 psig (4792 kPa)
Control Voltage
24 VAC, 1VA
Line Voltage Range
208 to 480 VAC
Start Voltage
10% to 40% of line (OEM specified - model specific)
Electrical Ratings
208 VAC
240 VAC
277 VAC
480 VAC
Full Load Amperes
8.0
8.0
6.9
4.0
Locked Rotor Amperes
16.5
16.5
14.3
10.5
Ambient Temperature
Maximum
130°F/54°C 130°F/54°C 130°F/54°C 150°F/66°C
Ambient Temperature
Minimum
-40°F/-40°C (at all Voltages)
Ambient Storage
Temperature
-40°F/-40°C to 185°F/85°C
Construction
Control Case
Galvanized steel case and cover
Base and Sensors
Galvanized steel
Plastic Enclosure
UV stabilized polycarbonate with closed cell foam gasket (NEMA 3R models only)
Enclosure
NEMA 1 or NEMA 3R (Rainproof)
Wiring Connections
Low Voltage
1/4 in. quick connects (NEMA 1); Two 6 in. 22 AWG Wire Leads (NEMA 3R)
Line Voltage
10-32 Screw Terminals
Pressure Connections
60 in./1524 mm or 120 in./3048 mm copper capillary with 1/4 in./6 mm flare nut and
Schrader valve depressor
Mounting
Vertical only; two holes for No. 10 screws at the top and bottom
Agency Listings
UL Recognized (U.S.): File SA516, Guide SDFY2
UL Recognized (Canada): File SA516, Guide SDFY8
CSA Certified: File LR 948, Class 1222 01 - Specific models only. Contact Johnson
Controls Application Engineering at 1-800-275-5676 for specific model information.
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, contact Johnson Controls Application Engineering at 1-800-275-5676. Johnson Controls shall not be liable for damages
resulting from misapplication or misuse of its products.
European Single Point of Contact: NA/SA Single Point of Contact: APAC Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142
CHINA
www.penncontrols.com
® Johnson Controls and PENN are registered trademarks of Johnson Controls in the
United States of America and/or other countries. All other trademarks used herein are the property
of their respective owners. © Copyright 2018 by Johnson Controls. All rights reserved.

Penn P66AAB-1 Specifications

Pressure Ratings

control range (low pressure models)	80 to 200 psig (552 to 1379 kPa)
control range (medium pressure models)	140 to 350 psig (965 to 2413 kPa)
control range (high pressure models)	300 to 500 psig (2048 to 3447 kPa)
effective throttling range (low pressure models)	30 psi (207 kPa)
effective throttling range (medium pressure models)	60 psi (414 kPa)
effective throttling range (high pressure models)	90 psi (621 kPa)
maximum working pressure (low pressure models)	200 psig (1379 kPa)
maximum working pressure (medium pressure models)	350 psig (2413 kPa)
maximum working pressure (high pressure models)	500 psig (3447 kPa)
maximum overpressure (low pressure models)	250 psig (1724 kPa)
maximum overpressure (medium pressure models)	400 psig (2758 kPa)
maximum overpressure (high pressure models)	695 psig (4792 kPa)

Electrical Ratings

control voltage	24 VAC, 1VA
line voltage range	208 to 480 VAC
full load amperes (208 VAC)	8.0
full load amperes (240 VAC)	8.0
full load amperes (277 VAC)	6.9
full load amperes (480 VAC)	4.0
locked rotor amperes (208 VAC)	16.5
locked rotor amperes (240 VAC)	16.5
locked rotor amperes (277 VAC)	14.3
locked rotor amperes (480 VAC)	10.5

Operating Environment

maximum ambient temperature (208 VAC)	130°F/54°C
maximum ambient temperature (240 VAC)	130°F/54°C
maximum ambient temperature (277 VAC)	130°F/54°C
maximum ambient temperature (480 VAC)	150°F/66°C
minimum ambient storage temperature	-40°F/-40°C (at all Voltages)
ambient storage temperature range	-40°F/-40°C to 185°F/85°C
