COLORVISION Light Installation and User’s Guide
COLORVISION Light Installation and User’s Guide
5
The following describes how to install the ColorVision Light fixture in concrete/
gunite, fiberglass or vinyl liner.
Be sure that the pool or spa meets the requirements of the current National Electrical
Code (NEC) Article 680-22 and all local codes and ordinances. A licensed or certified
electrician must install the electrical system to meet or exceed those requirements
before the underwater light is installed. Some of the requirements of the National
Electrical Code which the pool’s electrical system must meet are as follows:
BEFORE STARTING: The following instructions must be completed by the
electrician before the ColorVision light fixture is installed.
• The Junction Box and the low voltage transformer is located at least 4 in
(10.16 cm) above ground level or 8 in (20.3 cm) above maximum water
level, whichever is higher. The Junction Box must be at least 48 in
(1.22 m) from the edge of the pool. See Figure 1 on page 6.
• To be certain that the pool or spa electrical system meets all applicable
requirements, the electrician should also consult the local building
department.
INSTALLING THE COLORVISION
™
LIGHT FIXTURE
(NEW POOL CONSTRUCTION)
INSTALLING THE COLORVISION
LIGHT NICHE
IN A GUNITE/CONCRETE POOL
(AFTER ELECTRICAL REQUIREMENTS ARE MET)
• The ColorVision Light should be located at least 3 ft (91.4 cm) from any
walls or other ColorVision lights (bubblers).
• The ColorVision light should be installed in water depths between 2”
and 12 in (5.08 cm - 30.5 cm).
• The ColorVision light is designed to be installed flush with the pool
finish.
• The ColorVision light niche is designed for 1-1/2 in (3.81 cm) PVC pipe
for the water supply and 1 in (2.54 cm) conduit for the light cable.
Determine a location for the ColorVision Light
