2
Note: Refer to page 3 where (parts index number) is shown
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions
IntelliCenter™ Control System Installation Instructions Summary
Required Tools:
• Medium size flat blade screwdriver or 1/4” and 5/16” socket
REMOVING THE EXISTING OUTDOOR CONTROL PANEL ............................................................ 4
INSTALL THE NEW 4A AND 5A LOW VOLTAGE CIRCUIT BREAKERS BRACKET
AND SYSTEM TRANSFORMER ........................................................................................................... 6
INSTALLING THE INTELLICENTER CONTROL SYSTEM OUTDOOR CONTROL PANEL ........ 8
CONNECTING AND CONFIGURING POOL AND SPA EQUIPMENT ............................................ 9
INSTALLING THE WIRING LABEL ON THE ENCLOSURE FRONT DOOR ................................. 10
Note: INSTALLING THE WIRELESS ANTENNA KIT. See IntelliCenter Control System
Installation Guide.
CAUTION: For existing EasyTouch
®
Control Systems that have an IntelliChlor
®
SCG
reset button bracket, the IntelliCenter Control System upgrade cannot be applied to
the current system.
IntelliChlor SCG
reset button
bracket
CAUTION: If there are EasyTouch or IntelliTouch Control System installed accessories, such as an
Indoor Control Panel or Wireless Remote, they will no longer function after installing the IntelliCenter
Control System Upgrade Kit. In addition to the free IntelliCenter Control System phone app, the following
optional accessories can also be purchased.
• IntelliCenter Indoor Control Panel, White Faceplate - P/N 522035
• IntelliCenter Indoor Control Panel, Tan Faceplate - P/N 523058.
• IntelliCenter Indoor Control Panel, Black Faceplate - P/N 523059.
• IntelliCenter Wireless Remote with Transceiver -P/N 522036.
