FLECK 2510 Service Manual • 7
Item No. QTY Part No. Description
1 ..............1 ...... 13870 ..............Housing, Timer, 3200
2 ..............1 ...... 14265 ..............Clip, Sping
3 ..............3 ...... 14087 ..............Insulator
4 ..............1 ...... 10896 ..............Switch, Micro
5 ..............1 ...... 15320 ..............Switch, Micro, Timer
6 ..............2 ...... 11413 ..............Screw, Pan Hd Mach,
4-40 x 1-1/8
7 ..............1 ...... 13886 ..............Knob, 3200
8 ..............5 ...... 13296 ..............Screw, Hex Wsh, 6-20 x 1/2
9 ..............1 ...... 11999 ..............Label, Button
10 ............1 ...... 13018 ..............Pinion, Idler
11 ............1 ...... 13312 ..............Spring, Idler Shaft
12 ............1 ...... 13017 ..............Gear, Idler
13 ............1 ...... 13164 ..............Gear, Drive
14 ............1 ...... 13887 ..............Plate, Motor Mounting
15 ............1 ...... 18743-1 ..........Motor, 120V, 60Hz, 1/30 RPM
....... 18752-1 ..........Motor, 100V, 50Hz, 1/30 RPM
....... 18824-1 ..........Motor, 230V, 50Hz, 1/30 RPM
....... 18826-1 ..........Motor, 24V, 50Hz, 1/30 RPM
....... 19659-1 ..........Motor, 24V, 60Hz, 1/30 RPM
....... 19660-1 ..........Motor, 230V, 60Hz, 1/30 RPM
16 ............2 ...... 13278 ..............Screw, Fillister Hd
6-32 x .156
17 ............1 ...... 15424 ..............Spring, Detent, Timer
18 ............1 ...... 15066 ..............Ball, 1/4-inch, Delrin
19 ............1 ...... 15465 ..............Label, Caution
20 ............1 ...... 19210 ..............Program Wheel Assy
21 ............1 ...... 13911 ..............Gear, Main Drive, Timer
22 ...........17 ..... 41754 ..............Pin, Spring, 1/16 x 5/8 SS,
Timer
23 ............1 ...... 13011 ..............Arm, Cycle Actuator
24 ............1 ...... 13864 ..............Ring, Skipper Wheel
25 ............2 ...... 13311 ..............Spring, Detent, Timer
26 ............2 ...... 13300 ..............Ball, 1/4-inch, SS
27 ............1 ...... 14381 ..............Skipper Wheel Assy, 12 Day
....... 14860 ..............Skipper Wheel Assy, 7 Day
28 ............1 ...... 13014 ..............Pointer, Regeneration
29 ............1 ...... 40096-24 .........Dial, 12 AM Regen Assy,
Black
....... 40096-02 .........Dial, 2 AM Regen Assy, Black
30 ............1 ...... 13881 ..............Bracket, Hinger Timer
31 ............2 ...... 11384 ..............Screw, Phil, 6-32 x 1/4 Zinc
32 ............1 ...... 13902 ..............Harness, 3200
33 ............2 ...... 40422 ..............Nut, Wire, Tan
34 ............1 ...... 15354-01 .........Wire, Ground, 4 inches
35 ............1 ...... 14007 ..............Label, Time of Day
36 ............1 ...... * ......................Complete 3200 Time Clock
Timer Assembly
37 ..................... 60320-02 .........Switch Kit, 3200/9000 Timer
Auxiliary, Optional
38 ..................... 61420-03 .........Program Wheel, Gear Assy,
Filter 2 Min Per Pin
....... 61420-04 .........Program Wheel, Gear Assy,
Softener, 2 Min Per Pin
*See Powerhead Ordering Guide
Item No. QTY Part No. Description
3200 TIME CLOCK TIMER ASSEMBLY
CONTINUED
