INTELLIBRITE
®
5G Pool and Spa Lights Installation and User’s Guide
INTELLIBRITE
®
5G Pool and Spa Lights Installation and User’s Guide
Troubleshooting
Problem Cause/Action
Light does not function properly Check the light wiring connection to the junction box
at the pool side and to the AC power switch.
Be sure that there is proper AC power applied to
the light.
The light will not illuminate. Check the GFCI ground fault wiring and reset if
necessary.
IntellliBrite 5G 12 V Light with Light Fuse
Assembly
Replace FUSE assembly (see page 12):
Note: Replacing the fuse assembly may or may
not resolve this problem. In some instances the
fuse assembly will blow, and after replacing the
fuse the light’s circuit board is still not functional.
IntelliBrite
®
5G Pool Light (12V) Fuse Harness Replacement
The following describes how to replace the IntelliBrite 5G Pool Light fuse assembly (if
applicable) and the light main circuit board for the IntelliBrite 5G pool light.
IMPORTANT! Before replacing the fuse assembly note the following:
REPLACING THE INTELLIBRITE POOL LIGHT CIRCUIT BOARD
ASSEMBLY (IN AN EXISTING POOL)
9
1. Turn off main electrical switch or circuit breaker, as well as the switch which
operates the IntelliBrite light itself.
2. Before starting make sure that you have a new lens gasket (P/N 79101601) and
a IntelliBrite 5G pool light circuit board assembly (P/N 619875Z - 300w,
P/N 619916Z-400W, P/N 619917Z- 500w) ready to install (see page 11).
Removal and Installation of IntelliBrite 5G Light Circuit Board
D A N G E R !
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
Always disconnect power to the pool light at the circuit breaker
before servicing the light. Failure to do so could result in death
or serious injury to installer, service person, pool users, or
others due to electrical shock.
When replacing or reassembling the IntelliBrite Pool Circuit Board, the
Gasket (P/N 79101601) or Gasket and Lens (619864Z) MUST ALSO BE
REPLACED - SEE PAGE 18 FOR PART NUMBERS
To Next Page
