IntelliBrite
®
Controller-Systemschaltplan
WICHTIG! Wenn Sie 12 VAC IntelliBrite LED-Leuchten installieren, schließen Sie die Leuchten
am sekundären 12 VAC-Ausgang des Abwärtstransformators an. Verbinden Sie anschließend
den IntelliBrite Controller mit dem primären 230 VAC-Eingang des Abwärtstransformators.
Elektroschrank
Leistungs-
schalter
Schwarz
Weiß
Rot
Transformator
Primär
Sekundär
Bis zu 6
IntelliBrites
230 V
230 VAC
Deutsch
