IntelliFlo Installation and User’s Guide
Controls and LEDs (Continued)
Arrow buttons:
• Up arrow: Move one level up in the menu tree or increase a digit when editing a setting.
• Down arrow: Move one level down in the menu tree or decrease a digit when editing a setting.
• Left arrow: Move cursor left one digit when editing a setting.
• Right arrow: Move cursor right one digit when editing a setting.
Feature 1 button: Starts Feature 1 mode. The LED is lit when mode is active.
Feature 2 button: Starts Feature 2 mode. The LED is lit when mode is active.
Start/Stop button: Start or Stop the pump. When the LED is lit it indicates that the pump is currently running or
in a mode to start automatically.
Reset button: Reset alarm or alert.
LEDs
On: This green LED is on when IntelliFlo is powered on.
Warning: This LED is on if a warning condition is present.
Alarm: This LED is on if an alarm condition has occurred.
Control Panel LCD Display
LCD Display Lines:
• Line 1 - Mode and time. To set A.M. and P.M. time, refer to “Time and Contrast Menu” on page 22.
• Line 2 - Data
• Line 3 - Name of data in line 2
• Line 4 - Run status
9
10
11
12
13
14
15
