INTELLIFLO
®
Variable Speed Pump Installation and User’s Guide
26
INTELLIFLO
®
Variable Speed Pump Installation and User’s Guide
TECHNICAL DATA
Pump Dimensions
23.4in
594mm
11.8in
301mm
9.9in
253mm
9.1in
232mm
10.8in
275mm
12.4in
316mm
13.1in
333mm
7.8in
199mm
2.8in
71mm
5.6in
142mm
Pump Performance Curves (IntelliFlo i1 Pumps)
0
0
10
20
30
40
50
60
70
90
80
20 40 60 80 100 120
TOTAL DYNAMIC HEAD IN FT OF WATER
FLOW RATE IN US GALLONS PER MINUTE
A
SPEED 1
SPEED 2
SPEED 3
SPEED 4
B
C
I
L
N
O
J
K
M
D
E
F
G
H
P
Q
R
S
CURVE SPEED
A450 RPM
B660 RPM
D850 RPM
E1050 RPM
F1250 RPM
H1725 RPM
I1850 RPM
J2050 RPM
K2250 RPM
M2450 RPM
N2550 RPM
O2650 RPM
P2850 RPM
R3250 RPM
S3450 RPM
C750 RPM
G1500 RPM
L2350 RPM
Q3110 RPM
Electrical Specifications
Circuit Protection: Two-pole 20 AMP device at the Electrical Panel.
Input: 230 VAC, 50/60 Hz, 3200 Watts Maximum, 1 phase
Note: Refer to the pump motor label, and all national and local
electrical codes, for specific electrical requirements and specifications.
WEF VALUES
011028 WEF 6.1 THP 3.95
011059 WEF 7.5 THP 3.95
011060 WEF 6.9 THP 3.95

Pentair IntelliFlo Specifications

General

Pump Type	Variable Speed
Horsepower	3.0 HP
Voltage	230V
Energy Efficiency	Energy Star Certified
Warranty	3 years
Maximum Flow Rate	160 GPM
Wet End Material	Composite
Control Interface	Digital
Speed Settings	8 Programmable Speeds
