Pentair MICROBRITE - Wiring Lights to IntelliBrite Controller and Transformer; Troubleshooting MicroBrite Lights; Troubleshooting IntelliBrite Controller

MicroBrite Color and White Light Installation and User’s Guide MicroBrite Color and White Light Installation and User’s Guide
19
Troubleshooting (MicroBrite Lights)
Troubleshooting (IntelliBrite
Controller)
Wiring MicroBrite
™
Color and White LED Lights to
IntelliBrite
®
Controller and 300 Watt Transformer
The following diagram shows how to connect MicroBrite Lights to an IntelliBrite
Controller using a 300 Watt transformer. Note: For MicroBrite light operating
instructions, see page 2.
wire nut
120 VAC Input
12O VAC
Wall Outlet
GREEN
WHITE
BLACK
GREEN
WHITE
BLACK
WHITE
IntelliBrite Controller
RED
300 Watt
Transformer
AC Power cord
MicroBrite Lights
BLACK
12 VAC
Transformer
12 VAC Output
12 VAC
Light does not function properly: Be sure that there is 12 VAC power applied to
the light.
Both of the LEDs are flashing: Check the light wiring connection to the junction
box at the pool side and to the AC power switch.
The IntelliBrite Controller has detected that the load has exceeded the maximum
allowable wattage or the output is shorted out.
1.
Switch off the IntelliBrite Controller OFF. Remove excessive load or
short.
2. Press the IntelliBrite Controller power switch to pow
er on the unit.
Ensure that the LEDs are no longer flashing.
