MicroBrite Color and White Light Installation and User’s Guide
16
EasyTouch
®
Automation System
The following describes how to setup the MicroBrite Light from the EasyTouch
®
Control
System indoor control panel or the EasyTouch Automation System wireless control panel.
From the EasyTouch control panel you can control the light shows.
To set up a MicroBrite light circuit;
assign the “Light Circuit Name” to the relay circuit
(example; AUX 3, as “Pool Light”) and “Function”: assign the name “Pool Light” circuit in
the Circuit Func. menu as a “light” circuit (IntelliBrite). After assigning the circuit name
and function, the light circuit name “Pool Light” can be setup in the CONFIG menu for light
position, color etc.
To assign a Circuit Name go to: MENU > SETTINGS > CIRCUIT NAMES
Circuit Names
Circuit #: 1/18
Circuit : AUX 1
[POOL LIGHT ]
T
S
IntelliFlo
IntelliChlor
Circuit Names
Circuit Func.
T
S
S
1. Press the
Up/Down button
to select a circuit number 1/18. Press the Up
button two times to select
AUX 1
to choose this circuit for a light circuit On/
Off button. The circuit number (1/18) corresponds to its assigned circuit
name.
2. Press the
Up/Down button
to scroll through the list of preset names. Select
a name such as “Pool Light.” AUX 1 has now been assigned the circuit name
“Pool Light.”
To assign a Circuit Function go to: MENU > SETTINGS > CIRCUIT FUNC.
3. Press the Menu button to return to the Settings menu. Press the Down
button to and select “Circuit Func.” Press the Right button to access the
Circuit Func. menu.
4. Press the
Up/Down button
to select the already assigned circuit name “Pool
Light.”
5. Press the
Right button
to view “Circuit Functions” to assign to light circuit
“Pool Light.”
6. Press the
Up/Down button
to select the type of light circuit function to use.
Select “INTELLIBRITE” for the MicroBrite light circuit function.
7. Press the Menu button three times to return to the main screen.
Operating the MicroBrite lights:
The MicroBrite
light is ready to operate using the
EasyTouch control panel button 1 (auxiliary 1 circuit). To access the Lights menu screen
(special Light Features
), press
Menu > Lights
. The Lights menu settings are: MODES,
COLORS, ALL ON, ALL OFF, SYNC, MAGICSTREAM, CONFIG: From the Modes screen
you can control the color light shows. To access the Modes menu, press Menu > Lights >
Modes. See page 2 for MicroBrite color light shows.
Circuit / Func. :
[POOL LIGHT ]
[INTELLIBRITE ]
Freeze: No
T
S
SETTING UP MICROBRITE
™
COLOR AND WHITE LED LIGHTS
WITH EASYTOUCH
®
AND INTELLITOUCH
®
AUTOMATION SYSTEM
