MicroBrite Color and White Light Installation and User’s Guide
21
MicroBrite
™
Color and White LED Light Dimensions
THREADED ADAPTER
1.83” (46 mm)
3.0” (76 mm)
THREADED ADAPTER
INSTALLATION TOOL
1.82” (46.2 mm)
0.5” (12 mm)
SECTION VIEW
THREADED
ADAPTER -
FITS 1-1/2”
NPT & NPS
THREADS
