Pentair OptiFlo - Dimensional Data; Pump Curves

8
OPTIFLO Aboveground Pool Pump Installation and User's Guide
PUMP CURVES
0
10
20
30
40
50
60
0102030405060708090 100
Flow Rate in U.S GPM
Total Dynamic Head in Ft. of Water
METERS OF WATER
CUBIC METERS PER HOUR
0
5
10
15
0510 15 20
DIMENSIONAL DATA
7.8"
(198 mm)
9.8"
(249 mm)
10"
(254 mm)
9.3"
(236 mm)
4.1"
(104 mm)
7.3"
(185 mm)
3.5"
(89 mm)
