Pentair PC600-P - Sediment Filter Installation

Sediment lter position is at the discretion of your professional installer. As a general guideline, the sediment pre lter is
typically installed in the "pre" position (as shown above) for well-water applications. For city water applications, the sediment
lter is typically installed in the "post" position after the Carbon Water Filter System Tank.
SEDIMENT FILTER INSTALLATION
Top View Filter
Blue Filter Housing
Inlet Water
Supply
Mounting
Bracket
Sediment Filter Cover
Sediment Filter
O-Ring x2
Stand Pipe
Blue Filter Housing
WATER SOFTENER ALTERNATIVE WITH NATURSOFT® SALT-FREE TECHNOLOGY • 7
Top View Filter
Blue Filter Housing
Inlet Water
Supply
Mounting
Bracket
WATER SOFTENER ALTERNATIVE WITH NATURSOFT® SALT-FREE TECHNOLOGY • 7
Part 1
1.Unscrewthecoverfromthebluelterhousing.
2.Removetheplasticcoveringfromthesedimentlter.
3.Placethesedimentlterontothestandpipeinthebluelterhousingandsetaside.
Part 2
1. Shut off the water.
2.Attachtheltercovertothemountingbracketusingthesuppliedboltheadscrewsandwashers.Makesuretoproperly
 orientatetheINandOUTtomatchyourowpattern.
3. Attach the mounting bracket to the wall using the supplied phillips head screws.
4.Handtightenthebluelterhousingandthen,usingthesuppliedlterwrench,lightlysnugthehousingmakingsurenotto
over-tighten (counterclockwise).
5. Determine the size of your inlet water supply line.
Note
WHOLE HOUSE WATER FILTER SYSTEM • 7
