Pentair PC600-P - Carbon Water Filter System Tank Installation

3.InstallthettingsintotheINLETandOUTLETsidesofthebypassvalve.Followthediagramsuppliedwiththetting.
4.ConnecttheincomingwatersupplyfromthesedimentltertothettingontheINLETsideofthebypassvalve.
5.ConnecttheoutgoingwatersupplytotheOUTLETsideofthebypassvalve.
CARBON WATER FILTER SYSTEM TANK INSTALLATION
Do not over-tighten any of the ttings during installation.
Top View
Front View
Shut Off Valves
Sediment Filter
Water to Home
Fluoride
Filter
Bypass
T
Incoming
Water
Supply
PVC Fitting*
Bypass Valve
1" NPT Assembly
Outgoing
ater to
House
W
*Customer supplied;
choose appropriate connection
Carbon Water
Filter System
See "Troubleshooting" section on tips for leveling the tank.
If the tank is not level, lift the tank straight up 6 inches and tap it on the ground until the tank stands vertical.
The bottom of the tank is round and the boot allows the tank to stand upright.
Note
1. Level the Carbon Water Filter System Tank.
Visit Pentair.com/homewater to view our full line of installation kits.
Note
2. Determine the size and material of your incoming water supply line and choose the appropriate plumbing required to adapt
to the 1” male NPT Assembly.
CAUTION
The tting below is designed with a ¼" give to allow for proper pipe alignment. It will not leak and is intended to
have some exibility.
Note
Part Description Qty.
1" Plastic Male NPT Assembly:
V3007-04 WS1 Fitting 1" Plastic Male NPT
Assembly (2): O-Rings (2), Split Rings (2),
and Connectors (2)
1
bag
Split Ring
Quick Connect Nut
O-Ring
WATER SOFTENER ALTERNATIVE TANK INSTALLATION
8 • WHOLE HOUSE WATER FILTER SYSTEM
