4
Ground motor before
connecting to electrical
power supply.
Failure to ground motor
can cause severe or fatal
electrical shock hazard.
Do not ground to a gas
supply line.
To avoid dangerous or
fatal electrical shock,
turn OFF power to motor
before working on electrical
connections.
Supply voltage must be
within ±10% of
nameplate voltage. Incorrect
voltage can cause fire or seriously damage motor and
voids warranty. If in doubt consult a licensed
electrician.
Use wire size specified in Wiring Chart (below). If
possible, connect pump to a separate branch
circuit with no other appliances on it.
Wire motor according to diagram in motor
junction box.
WIRING
1. Install, ground, wire and maintain this pump in
accordance with electrical code requirements. Consult
your local building inspector for information about
codes.
2. Provide a correctly fused disconnect switch for
protection while working on motor. Consult local or
national electrical codes for switch requirements.
3. Disconnect power before servicing motor or pump.
If the disconnect switch is out of sight of pump,
lock it open and tag it to prevent unexpected power
application.
4. Ground the pump permanently using a wire of the
same size as that specified in wiring chart (below).
Make ground connection to green grounding terminal in
motor junction box marked GRD. or .
5. Connect ground wire to a grounded lead in the service
panel or to a metal underground water pipe or well
casing at least 10 feet long. Do not connect to plastic
pipe or insulated fittings.
6. Protect current carrying and grounding conductors from
cuts, grease, heat, oil, and chemicals.
7. Connect current carrying conductors to terminals in
motor junction box. When replacing motor, check
wiring diagram in motor junction box for correct wiring
connections.
WARNING
Hazardous voltage.
Can shock, burn, or
cause death.
Ground pump before
connecting to power
supply.
TABLE II - RECOMMENDED FUSING AND WIRING DATA - 60 CYCLE MOTORS
*A Fusetron is recommended instead of a fuse in any motor circuit
ELECTRICAL
DISTANCE IN FEET FROM MOTOR TO METER
BRANCH 0’ 101’ 201’ 301’ 401’
MOTOR MAX. LOAD FUSE* TO TO TO TO TO
HP AMPERES RATING VOLT/ 100’ 200’ 300’ 400’ 500’
AMPS PHASE
WIRE SIZE
SINGLE PHASE - 115/230 VOLT
1/3 8.2/4.1 15/15 115/230/1 14/14(2/2) 12/14(3/2) 10/14(5.5/2) 8/14(8.4/2) 8/12(8.4/3)
1/2 8.2/4.1 15/15 115/230/1 14/14(2/2) 12/14(3/2) 10/14(5.5/2) 8/14(8.4/2) 8/12(8.4/3)
3/4 11.6/5.8 15/15 115/230/1 14/14(2/2) 10/14(5.5/2) 8/14(8.4/2) 6/14(14/2) 6/12(14/3)
1 14.2/7.1 20/15 115/230/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2) 6/12(14/3) 4/10(21/5.5)
1-1/2 18.0/9.0 25/15 115/230/1 10/14(5.5/2) 8/14(8.4/2) 6/12(14/3) 6/12(14/3) 4/10(21/5.5)
THREE PHASE - 230/460 VOLT
1/2 2.2/1.1 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2)
3/4 2.9/1.45 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2)
1 3.6/1.8 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2)
1-1/2 4.8/2.4 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2)
2 6.0/3.0 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 14/14(2/2) 12/14(3/2)
2-1/2 7.0/3.5 15/15 230/460/3 14/14(2/2) 14/14(2/2) 14/14(2/2) 12/14(3/2) 12/14(3/2)
SINGLE PHASE - 230 VOLT
2 10.4 15 230/1 14(2) 14(2) 12(3) 10(5.5) 10(5.5)
2-1/2 11.7 15 230/1 14(2) 14(2) 12(3) 10(5.5) 10(5.5)
SINGLE PHASE - 100-200 VOLT
3/4 12.0/6.0 15/15 100/200/1 14/14(2/2) 10/14(5.5/2) 8/14(8.4/2) 6/14(14/2) 6/12(14/3)
