Pentair Sta-Rite J Series - Motor Wiring Connections

5
8. Motor has automatic internal thermal overload
protection. If motor has stopped for unknown reasons,
thermal overload may restart it unexpectedly, which
could cause injury or property damage. Disconnect
power before servicing motor.
9. If this procedure or the wiring diagrams are confusing,
consult a licensed electrician.
ELECTRICAL
Connect wires to motor according to wiring diagram
below or in motor junction box. Be sure motor is
connected for correct line voltage. If diagram in
motor junction box is different from diagram in this
manual, follow diagram on motor.
For All 3-phase Motors: Follow wiring diagram in
motor junction box or on motor nameplate.
Figure 3 - Motor wiring connections for 100/200V, 115/230V, and 230V only motors
(single phase).
L2
Blue
Black Tracer
Red
Purple
Black
White
L1
L2
Blue
Black Tracer
Red
Purple
Black
White
L1
Low Voltage
115/230V Dual Voltage 230V Single Voltage
High Voltage
L2
Blue
White
L1
3320 0998 WG
