77420 - 51/107 -
21-3-2．Beta Adjustment (Square)
①Click [BETA ADJUSTMENT]
②Click [START]
③Attach the AF position jig (Square) to the camera and set the Light source toLV12.
Set the camera (with AF position jig) to center of Light source window and click [OK].
④Turn the adjustment screw No.3 (or No.1) by HD driver (HD-M1.5) until green is indicated on Value
window(OK).
⑤ When green (OK) is displayed, click [Stop].
①
To Next Page
