77420 - 72/107 -
6-3.WDC Adjustment (If necessary)
It can be adjusted only for white pixel defect compensation separately.
(Light source and Master lens are not necessary for this adjustment)
*There is possibility that pixel defect compensation can be adjusted by adjust repeatly.
[Required equipments]
□Programmed software for 77420 [K-r CS_MTest]
①Set mode dial to [M] and Set focus mode lever to [MF].
②Connect the camera and PC with USB cable and turn ON the camera.
③Double click [K-r SLR_ MTest.exe] in adjustment folder to start up software.
④Select WDC and click [Execute] to start adjustment.
⑤When adjustment is completed, [OK] will be displayed.
⑥Click [END] to finish adjustment software.
To Next Page
