Pentax AL-M Series User Manual

- 28 -
Fig.4.6
2) The distance between level and surveyor’s rod is equal to L multiple 100.
Example： If the length l=1.652-1.332=0.320m=32cm， the horizontal
distance from the instrument to the surveyor’s rod is 0.32m ×
100=32m( Fig.4.7 ).
Stadia lines
