15
1.4 Battery insertion
Battery insertion for the instrument
Turn the detaching knob for battery cap counterclockwise and remove
the cap from the instrument.
Insert 4 pcs D type batteries into the battery box according to its
(+) and (-) marks. (PLP-701 / PLP-702)
Insert the rechargeable NI-MH batteries with body into the
battery box. (PLP-701R/PLP-702R).
While holding the instrument with one hand, push the battery cap into
the battery box and attach it by turning the knob clockwise.
1
2
3
