3.2 Setting up the instrument

[Mounting on the tripod]

Mount the instrument on the tripod head and while supporting the

instrument with one hand, secure it using the tripod center screw.

NOTE:

• Also when removing the instrument from the tripod, loosen the

center screw while supporting the instrument with one hand.

• Do not leave the instrument mounted on tripod without the center

screw being tightened. It may cause the instrument to fall and be

damaged.

Instrument

Tripod head

Center screw
