Model R-202NE R-205NE
Telescope Magnification 30 x
Effective aperture 45mm (EDM45mm)
Resolving power 3.0”
Field of view 2.6 % (1° 30’)
Minimum focus 1.0 m
Focus Manual
Distance measurement
Laser Class Visible laser: Class III a (3R) (Reflectorless) / Class II (2) (Prism, sheet)
Measurement range Reflectorless
(*1)
1.5 ~ 350 m
(Good conditions) (*3) Reflector sheet
(*2)
1.5 ~ 600 m (800 m)
Mini Prism 1.5 ~ 1,100 m (2,000 m)
1 P 1.5 ~ 3,000 m (4,000 m)
3 P 1.5 ~ 4,000 m (5,200 m)
Accuracy Prism / Reflector sheet 1.5 ~ 10 m: ± (3 + 2 ppm x D) mm / 10 m ~: ± (2 + 2 ppm x D) mm, Quick: ± (3+2ppm×D) mm
(*5)
Reflectorless 1.5 ~ 300 m: ± (5 + 2 ppm x D) mm / 300 m ~: ± (7 + 10 ppm x D) mm
Minimum count 0.1 mm (Fine mode) / 1 mm (Normal mode) / 10mm (Track mode)
Meassuring time (*4)
Repeat meas. Normal (1 mm) Prism / Reflector sheet 2.0 sec - Reflectorless 2.0 sec
Quick (1 mm) Prism / Reflector sheet 1.2 sec
(*5)
Track (10 mm) Prism / Reflector sheet 0.4 sec - Reflectorless 0.4 sec
Initial meas. Normal (1 mm) Prism / Reflector sheet 2.5 sec - Reflectorless 2.4 sec
Quick (1 mm) Prism / Reflector sheet 1.7 sec
(*5)
Track (10 mm) Prism / Reflector sheet 2.5 sec - Reflectorless 2.5 sec
Angle measurement Measurement method Absolute rotary encoder
Direction method Vertical / Horizontal angle: 2 sides Vertical / Horizontal angle: 1 side
Minimum count 1” / 5” selectable
Accuracy (ISO 17123-3) 2” 5”
Compensator Axis Single Single
Range ±3’
Target screw 1 speed
Sensitivity of vials Plate level 30” / 1 mm
Circular level 8’ / 2 mm
Plummet Laser Plummet
Base Detachable
Dust & water resistance IP56 (instrument only)
Ambient temperature -20°C ~ +50°C / -4°F ~ 122°F (working range)
Tripod thread 5/8” x 11
Dimensions / Weight Dimensions 172 (W) x 342 (H) x 177 (L) mm
Weight (incl. battery) 5.7 kg
Carrying case 250 (W) x 365 (H) x 425 (L) mm
Battery pack Power source Ni-MH 4300 mAh (rechargeable) DC 6.0 V
Operation time Approx. 7.0 hrs (ETH + EDM, single measurement every 30 sec.), 15hrs (ETH) with approx. 2.2 hrs of charging time
Weight 380 g
Battery charger Input Voltage AC 100 ~ 240 V
and AC adapter Output Voltage DC 7.5 V
Weight 280 g
Data Process Data recording method Internal Memory
Coordinates data
(*6)
20,000
Special function PowerTopoLite
I / F RS-232C
Display / keyboard Display type Graphic LCD / 20 characters x 8 lines / 240 x 96 pixels
Quantity double
Keys 22 each(12 numeric / 5 function / 5 special)
Display back light Intensity settings: 10 steps
Laser Pointer Yes
Date clock Yes
Total Station R-200 Series Specifications
* Designs and specications are subject to change without notice, conguration is subject to changes per country, please contact your local dealer. - Printed in Belgium - ZAS591400 - © PENTAX 2013 - SURVEY/11/2013
