2
6.2 Distance measurement 31
6.3 Quick mode 32
7. CORRECTION MODE 33
7.1 Changing the target constant 33
7.2 Changing the temperature 34
7.3 Changing the atmospheric pressure 35
7.4 Changing the ppm value 36
8. INITIAL SETTING 38
8.1 Overview 38
8.2 Entering the mode for initial setting 1 38
8.3 Entering the mode for initial setting 2 38
8.4 Entering the mode for initial setting 4 38
8.5 Entering the mode for initial setting 5 38
8.6 Example of changing an initial setting content
(selection of atmospheric correction) 39
8.7 Initial setting 1 40
8.8 Initial setting 2 40
8.9 Initial setting 4 41
8.10Initial setting 5 42
9. ACCESSING THE FUNCTIONS 43
9.1 Accessing by help key 43
9.2 Accessing by 007 43
Instrument setting items 44
10. CHECKS AND ADJUSTMENTS 45
10.1 Plate level 45
10.2 Circular vial 45
10.3 Vertical reticle 46
10.4 Perpendicularity of line of sight to horizontal axis 47
10.5 Vertical 0 point error 48
10.6 Laser plummet 48
10.7 Optical plummet 49
10.8 Offset constant 49
10.9 Beam axis and line of sight 50
10.10 The EDM beam axis 51
11. Specifications 53
12. Data collector 55
13. APPENDIX 56
13.1 Warning and Error Messages 56
13.2 Atmospheric correction 56
13.3 hPa and mmHg conversion table 57
13.4 Error when no atmospheric correction is made 57
13.5 Atmospheric refraction and earth curvature correction 58
