TABLET Installation
TABLET Installation
Before proceeding, verify that you have completed the procedures in the PeopleNet Installation Manual through
page 28. These include the following three procedures:
• Mounting the g3 onboard computer (OBC)
• Mounting and connecting antennas
• Connecting the Main Cable to the OBC and the vehicle’s power source
Once you have verified that they are completed, proceed with “Mounting the TABLET Dock” below.
Mounting the TABLET Dock
You will need the TABLET Dock Installation Kit for this procedure.
1. Determine a physical mounting location for the TABLET Dock that will not
• Impede the driver’s vision, or
• Cause damage to the truck from the weight of the device.
Refer to “Installation Examples” on page 22 for pictures of a mounted TABLET Dock.
2. Bolt the TABLET Dock to the “L” Support Brace.
3. Secure the “L” Support Brace to the dash.
4. Verify that both the “L” Support Brace and the TABLET Dock are securely mounted.
5. Place the TABLET into the TABLET Dock.
6. Lock the TABLET in place with the locking mechanism on the top of the TABLET Dock.
The TABLET Dock is now mounted.
