PeopleNet System Installation Manual
© 2010 PeopleNet Communications. All rights reserved.
PeopleNet System Installation Manual
You need to complete some of the procedures in the PeopleNet Installation Manual before proceeding with this
guide. These include the following three procedures:
• Mounting the g3 onboard computer (OBC)
• Mounting and connecting antennas
• Connecting the Main Cable to the OBC and the vehicle’s power source
Figure 1: PeopleNet Installation Manual
TABLET
This is the TABLET device itself and the TABLET in the TABLET Dock.
Figure 2: The TABLET device
Part #:
M-010-0250
