TABLET-OBC Synchronization Process
TABLET-OBC Synchronization Process
Starting at the Process Installation window with the prompt, “…Would you like to process an installation?”
1. Select Yes.
You are prompted with “Is this a new installation?”
2. If the g3/OBC is brand new, select “Yes”.
a. If the g3/OBC is currently active in the PFM(PeopleNet Feet Manager), select “No”
3. Enter your Installer Number and press the Tab key.
4. Enter your Truck Number.
5. Press SUBMIT.
• If the 2
nd
green LED stops flashing and the screen has not changed, press Data Call to continue the
installation.
• The screen will eventually change and you will receive a message confirming successful installation.
Process Installation is now complete.
Important: If the activation message is not displayed, contact PeopleNet Support at 888-346-3486.
