peplink PEPWAVE HD Dome Pro User Manual

2.15 MAX HD2 and HD4 with MediaFast
2.15.1 Panel Appearance
Note:
- For proper Wi-Fi performance and operations, please ensure all 4 Wi-Fi antenna
connectors (labeled Wi-Fi 1 and Wi-Fi 2) have antennas attached.
- The LED indicators of Wi-Fi 1 & 2 shown as below is referring to the default settings of
Wi-Fi Operation mode is WAN + AP under the AP. For more details, please refer to the
section 25.4.
2.15.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF
System initializing
Red
Booting up or busy
Blinking red
Boot up error
Green
Ready
https://www.peplink.com
36
Copyright @ 2021 Peplink
