OFF
10 Mbps / 100 Mbps or port is not connected
Orange LED
ON
Port is connected without traffic
Blinking
Data is transferring
OFF
Port is not connected
Port Type
Auto MDI/MDI-X ports
2.17 MAX HD4 MBX (CAT-12)
For certification information, please refer to Appendix B: Declaration
2.17.1 Panel Appearance
Note:
- For proper Wi-Fi performance and operations, please ensure all 4 Wi-Fi antenna
connectors (labeled Wi-Fi 1 and Wi-Fi 2) have antennas attached.
https://www.peplink.com
40
Copyright @ 2021 Peplink
