2.16.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF
System initializing
Red
Booting up or busy
Blinking red
Boot up error
Green
Ready
Wi-Fi WAN Indicators
Wi-Fi 1
OFF
Disabled Intermittent
Blinking slowly
Connecting to wireless network(s)
Blinking
Connected to wireless network(s) with traffic
ON
Connected to wireless network(s) without traffic
Wi-Fi AP Indicators
Wi-Fi 2
OFF
WiFi AP is disabled.
ON
WiFi AP is enabled.
Cellular Indicators
Cellular 1 / 2 /
3 / 4
OFF
Disabled or no SIM card inserted
Blinking slowly
Connecting to network(s)
Green
Connected to network(s)
LAN Ports
Green LED
ON
POE Enabled
OFF
POE Disabled
Orange LED
Blinking
10 / 100 / 1000 Mbps and Data is transferring
OFF
No data is being transferred or port is not connected
Port Type
Auto MDI/MDI-X ports
Ethernet WAN Ports
Green LED
ON
1000 Mbps
