IDENT-I • IVI-KHA6-4HRX, IVI-KHD2-4HRX
Commands
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
P
epperl+Fuchs Group • Tel.: Germany (06 21) 7 76-0 • USA (330) 4 25 35 55 • Singapore 7 79 90 91 • Internet http://www.pepperl-fuchs.com
Date of issue 27.08.2001
27
Example: Write "P+F" to the data carrier at start address 10, in auto mode and
using read head No. 2:
Complete command: K 2 0A 03 50h 2Bh 46h 12h 03h
If the hex sum is, e.g.: 72h,
then the check sum is: 72h.
If, as above, the hex sum is: 212h,
this gives a check sum of: 12h.
K 2 0 A 0 3 50
h
2B
h
46
h
12
h
4B
h
+ 32
h
+ 30
h
+ 41
h
+ 30
h
+ 33
h
+ 50
h
+ 2B
h
+ 46
h
= (2)12
h
