8.2.3 Fixed code read commands
Bild 8.11: Fixed code read commands
Read commands for the basic fixed code operating mode
with read head number
When a read head is specified in a command, it is interrogated once only. The result
(code or error message) will then be transmitted in a SEND message. After successful
transmission, the control interface unit waits for another command.
Bild 8.12: Structure of response message after a code has been read
Example: A code was read at read head 4
Read-command without read head number
All connected heads are interrogated once. The codes which are read are transmitted
in packed form in a message. The data structure is as for commands R1 … R4.
Example: A code was read at read head 2 and 4.
Response: 20 0A 1A 66 0C 8F 4A 65 11 78
Command Hex identifier
Read Fixed code 20h
Buffered Read Fixed code 21h
Byte 1
High
Byte 2
Low
Byte 2
High
Byte 3
Low
Byte 3
Byte 4 ...
Byte 6
20h 0 Head
Status
Head-no. Code Code
} } } } } }
