K-System – Isolated Barriers

Technical Specifications

Figure 7.7 Dimensions (W x H x D): 40 x 93 x 115 mm (1.6 x 3.7 x 4.5 inch)

Figure 7.8 Dimensions (W x H x D): 140 x 99 x 103,5 mm (5.5 x 3.9 x 4.1 inch)

Housing Type E

Housing Power Supply 4 A

115 mm

93 mm

40 mm

140 mm88 mm

99 mm

103.5 mm

PE L1 N

Primary Secondary
