Pepperl+Fuchs VAG-PB-KF-R4 User Manual

AS-i/PROFIBUS Gateway
Connections, Displays and Controls
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (621) 776-0 · USA (330) 4253555 · Singapore 7799091 · Internet http://www.pepperl-fuchs.com
issue date 12.10.1999
17
and to terminal 25. The RxD/TxD-N signal (A cable per PROFIBUS specifications) is
assigned to pin 8 and to terminal 26.
In order to prevent equalizing currents, the interface cable's shielding is connected
with the gateways grounding clamp through a capacitor. Otherwise, it should be gal-
vanically grounded.
