AS-Interface
Appendix: The First Commissioning of AS-i
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (621) 776-0 · USA (330) 4253555 · Singapore 7799091 · Internet http://www.pepperl-fuchs.com
issue date 12.10.1999
58
Change to the protected operating mode
and store the AS-i configuration.
Leave the configuration mode by press-
ing the "mode" button for at least five
seconds until the "prj mode" LED goes
out.
The configuration of the master is now finished.
If the AS-i Master is a gateway, the hierarchically higher fieldbus system can be put
into operation now.
The gateway stays in the off-line phase (the display shows "40"), the LED
"config err" lights up), until the hierarchically higher fieldbus system oper-
ates properly.
What to do ? How to go about it?
