SLG2008A
Owner’s Manual
11
Step 9
a) Connect the side burner ignition cable
by inserting it into the electrode.
Make certain the connection is secure.
Step 10
a) Place the three heat plates (KK) inside the grill upon
the burners.
b) Place the two cooking grates (LL) inside the grill upon
the heating shields.
c) Insert the four feet of warming grate-body (MM) into
the holes on top of grill body.
d) Insert two ends of side warming grate-lid (SS) into the
holes on inside the top lid.
To Next Page
