Peri MULTIPROP MP 120 - Page 17

15
MP 250 + MP 50
L = 1.95 – 3.00 m
MP 350 + MP 50
L = 2.45 – 4.00 m
MP 480 + MP 50
L = 3.10 – 5.30 m
MP 625 + MP 50
L = 4.80 – 6.75 m
2.25 76.6 73.6
2.30 74.5 72.9
2.40 72.4 72.1
2.50 66.1 69.8 87.6 84.2
2.60 63.3 67.7 83.8 82.9
2.70 60.5 65.6 79.9 81.7
2.80 57.7 63.1 76.1 80.5
2.90 55.1 60.1 70.0 77.0
3.00 52.4 57.1 63.9 73.5
3.10 60.8 70.6 76.8 73.3
3.20 57.6 67.6 74.4 72.8
3.30 55.2 64.7 71.9 72.3
3.40 52.7 61.8 69.4 71.8
3.50 50.8 59.1 67.0 71.3
3.60 48.8 56.4 62.6 70.0
3.70 46.9 52.2 58.2 68.7
3.80 45.0 48.0 53.9 67.4
3.90 41.8 43.9 51.2 62.9
4.00 38.5 39.8 48.6 58.4
4.10 45.9 53.9
4.20 43.9 50.1
4.30 41.9 46.3
4.40 39.8 42.5
4.50 37.7 40.0
4.60 35.5 37.5
4.70 33.3 35.0
4.80 31.7 33.2 48.7 44.5
4.90 30.0 31.4 47.5 44.4
5.00 28.4 29.6 46.2 44.3
5.10 26.7 27.8 44.5 43.1
5.20 25.1 26.0 42.8 41.8
5.30 23.4 24.2 41.1 40.4
5.40 40.1 39.6
5.50 37.3 37.2
5.60 35.3 35.6
5.70 33.3 34.0
5.80 31.5 32.5
5.90 30.6 31.7
6.00 28.1 29.5
6.10 26.7 28.1
6.20 25.3 26.7
6.30 24.1 25.4
6.40 23.5 24.8
6.50 21.8 22.9
6.60 20.8 21.7
6.70 19.8 20.6
6.75 19.3 20.0
Instructions for Assembly and Use – Standard Configuration
MULTIPROP Slab Props
Table for MULTIPROP 250, 350, 480, 625
with Base MP 50
Permissible prop load [kN] according to the type test
Overall height
[m]
(prop extension
+ 50 cm)
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Note:
To release the loads > 60 kN we recommend using the HD Wingnut Spanner,
Item no. 022027.
EX_AuV_MULTIPROP_MP_Deckenstutzen.indb 15 24.03.16 15:10
