14
MP 250
L = 1.45 – 2.50 m
MP 350
L = 1.95 – 3.50 m
MP 480
L = 2.60 – 4.80 m
MP 625
L = 4.30 – 6.25 m
1.45 75.5 78.5
1.50 75.5 78.5
1.60 75.5 78.5
1.70 75.5 78.5
1.80 73.8 78.5
1.90 70.6 78.5
1.95 68.0 78.5 91.0 90.1
2.00 67.3 78.5 91.0 90.1
2.10 65.7 76.8 86.0 90.1
2.20 64.1 75.1 80.6 90.1
2.30 62.5 72.6 75.1 89.8
2.40 60.8 69.1 70.7 87.9
2.50 59.2 65.6 66.4 86.1
2.60 63.7 83.1 88.5 73.6
2.70 61.1 80.1 83.7 73.3
2.80 59.2 77.1 78.8 72.9
2.90 57.4 74.1 74.0 72.6
3.00 56.0 70.3 69.1 72.2
3.10 54.5 66.6 64.9 71.4
3.20 52.9 61.8 60.7 70.7
3.30 51.3 57.1 56.5 70.0
3.40 47.7 51.7 54.1 68.2
3.50 44.2 46.4 51.8 66.5
3.60 49.4 64.7
3.70 47.5 60.4
3.80 45.7 56.1
3.90 43.8 51.8
4.00 41.8 48.4
4.10 39.7 45.0
4.20 37.7 41.6
4.30 35.8 39.3 57.9 45.7
4.40 33.9 37.0 56.3 45.7
4.50 32.0 34.8 54.7 45.7
4.60 30.2 32.5 52.5 45.1
4.70 28.3 30.2 50.3 44.4
4.80 26.4 27.9 47.9 43.5
4.90 45.2 42.4
5.00 42.5 41.3
5.10 39.9 39.9
5.20 37.2 38.5
5.30 34.9 37.1
5.40 32.8 35.6
5.50 30.8 34.1
5.60 29.3 32.6
5.70 27.8 31.2
5.80 26.4 29.6
5.90 25.1 27.9
6.00 23.8 26.2
6.10 22.7 24.8
6.20 21.6 23.4
6.25 21.0 22.7
Instructions for Assembly and Use – Standard Configuration
MULTIPROP Slab Props
Table for MULTIPROP 250, 350, 480, 625
Permissible prop load [kN] according to the type test
Extension
length [m]
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
MULTIPROP Props are classified according to official approval as follows:
MP 250 = Class T 25
MP 350 = Class R 35
MP 480 = Class D 45
MP 625 = Class D 60
Note:
To release the loads > 60 kN we recommend using the HD Wingnut Spanner,
Item no. 022027.
When using PERI slab tables, the permissible load on the MULTIPROP MP 350
Prop is a minimum of 56 kN and a minimum of 36 kN for the MULTIPROP MP
480 over the entire extension length – this is due to the props being clamped in
the Table Swivel Head or UNIPORTAL Head.
