Instructions for Assembly and Use – Standard Configuration
MULTIPROP Slab Props
A4 Foreseeable misapplications
Applications of this type or similar are prohibited!
Ensure that slab props are always in
a perpendicular position!
Fig. A4.01
Non-loadable installation surface!
Fig. A4.03a
Only use full-faced support surfaces!
Fig. A4.02a Fig. A4.02b
Fig. A4.03b
Slab props must always be in a vertical
position.
End plates of the slab props must always lie completely flat.
If necessary, fill the gap and secure the wedge.
Slab props must always be positioned
on sufficiently load-bearing and flat sur-
faces.
