8 . Lambda 265, 365 and 465 ASX-260/280 AND ASX-520/560 Autosampler Users Guide
Dimensions and Specifications
Dimensions of AutoSampler
Physical
Characteristic
Specification
ASX-260 ASX-520
Power 100-240 VAC, 47/63 Hz
Dimensions (mm) 330 (W) x 508 (D) x 610 (H) 520 (W) x 482 (D) x 610 (H)
Weight (kg) 8.4 10.5
Tray 2 racks capacity 4 racks capacity
Physical
Characteristic
Specification
ASX-280 ASX-560
Power 100-240 VAC, 47/63 Hz
Dimensions (mm) 355 (W) x 550 (D) x 620 (H) 580 (W) x 550 (D) x 620 (H)
Weight (kg) 8.1 11.7
Tray 2 racks capacity 4 racks capacity
Specifications of Peristaltic Pump
Specifications
Speed (rpm) 0.1 to 100
Flow rate* 0.0002 - 35 ml/min/channel (tubing dependent)
Motor type Stepper motors
Channels 2
Tubing i.d.(mm) 0.13 to 3.17
Temperature, operating (°C) -5 to 40
Humidity Up to 80%
Dimensions (mm) 170 (H) x 125 (W) x 193 (D)
Power 30 W, 100 – 240 VAC, 50/60 Hz
Weight (kg) 2.7
