PerkinElmer Lambda 365 Assembly/Installation Instructions

09931295C
7
Lambda 365 Installation
CAUTION
ATTENTION
Make sure the instrument is turned off while installing this accessory.
Assurez-vous que l’instrument est éteint lors de l’installation de cet
accessoire.
Connect to Single Cell Holder
1. Connect the plug of the power cable to the power input socket of the control unit.
Figure 8 Connecting the plug
2. Connect the stirrer control cable to the 4-pin socket of the control unit.
Figure 9 Connecting the stirrer control cable

PerkinElmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 V AC, 50/60 Hz
Wavelength Accuracy	±0.3 nm
Wavelength Repeatability	±0.1 nm
Wavelength Reproducibility	±0.1 nm
Photometric Repeatability	±0.001 Abs
Baseline Flatness	±0.0005 Abs
Baseline Stability	<0.0003 Abs/hour (after warm-up)
Data Interval	0.1 - 5 nm
Light Source	Tungsten halogen lamp and deuterium lamp
Sample Compartment	Standard 10 mm cell holder
Detector	Silicon Photodiode
