Cap A
Illustration 92 g03814811
1. Remove cap (A) from breather body (7). Remove
the filter element (6) from breather body. Discard
old filter element.
2. If necessary, remove O ring seal (5) and discard.
3. Ensure correct orientation of new filter element (6)
and install filter element in to breather body. If
necessary, install new O ring seal to cap (A).
4. Install cap (A) hand pressure only.
Cap B
Illustration 93 g03814824
1. Loosen clip (1) and remove hose (2). Loosen clip
(3) and remove hose (4). Refer to illustration 91 .
2. Remove cap (B) from breather body (7). If
necessary, remove O ring seal (8) and discard.
3. Remove filter element (6) from breather body and
discard old filter element.
4. If necessary, install new O ring seal (8).
5. Ensure correct orientation of new filter element (6)
and install filter element in to breather body.
6. Install cap (B) hand pressure only.
SEBU9071-06
113
Maintenance Section
If Equipped
