(Table 4, contd)
Transmission Default Torque Limit Reset Not Reset
Air Filter Restriction Switch Installation Status Not Installed
Air Filter Restriction Switch Configuration Normally Open
Intermediate Engine Speed 1400. rpm
Air Shutoff Disabled
Air Intake Shutoff Detection Installation Status Not Installed
Coolant Level Sensor Not Installed
Engine Retarder Enable Command Disabled
Auxiliary Temperature Sensor Installation Status Not Installed
Auxiliary Temperature Sensor #2 Installation Status Not Installed
Auxiliary Pressure Sensor Installation Status Not Installed
Engine Governor Primary Mode Configuration Speed Control
DPF Regeneration Enable Input Configuration CAN Input
Limp Home Desired Engine Speed 1200. rpm
Limp Home Engine Speed Ramp Rate 200. rpm/s
Throttle Input Low Idle Duty Cycle Setpoint 10 Percent
Throttle Input High Idle Duty Cycle Setpoint 90 Percent
Throttle Input #2 Low Idle Duty Cycle Setpoint 10 Percent
Throttle Input #2 High Idle Duty Cycle Setpoint 90 Percent
Throttle Failure Mode Latch Enable Status Enabled
Throttle #1 Engine Speed Droop 5 Percent
Throttle #2 Engine Speed Droop 5 Percent
Data Link Engine Speed Droop 5 Percent
Droop No Load Fuel Offset 0 Percent
Throttle Lock Feature Installation Status Not Installed
PTO Mode Set/Resume
Throttle Lock Engine Set Speed #1 600 rpm
Throttle Lock Engine Set Speed #2 600 rpm
Throttle Lock Increment Speed Ramp Rate 400. rpm/s
Throttle Lock Decrement Speed Ramp Rate 400 rpm/s
Throttle Lock Engine Set Speed Increment 10. rpm
Throttle Lock Engine Set Speed Decrement 10. rpm
Engine Fan Control Off
Engine Fan Type Configuration Variable Hydraulic
Engine Fan Speed Control Configuration Disabled or Not Installed
Engine Fan Reversing Feature Disabled
(continued)
46
SEBU9071-06
Operation Section
Configuration Parameters
