Perkins 6TG2AM - Power Take-Off (PTO); Belt Drives - 4.4 GM, 4.4 TGM, 4.4 TWGM and 4.4 TW2 GM Only

N38143 Chapter 5
Page 35
Belt drives - 4.4GM, 4.4TGM, 4.4TWGM and 4.4TW2GM only.
Standard options are:-
Fenner 5” A section pulley with three grooves (A1) and taper lock (A2).
or
A Fenner 5” B section pulley with two grooves (A3) and taper locks (A4).
In this case the maximum power which can be taken will be limited by the belts, and it will be necessary to
calculate for marginal applications.
Caution: Additional inertia must not be added to the P.T.O. shaft without specialist advice. Consult your
distributor if you need advice about non-standard drive arrangements.
•
•
Power take-off (not optional on the 415GM, 422GM & 422TGM)
