Chapter 5 N38143
Page 38
Belt drives - 6TG2AM and 6TWGM only.
Standard options are:-
Fenner 5” A section pulley with three grooves (A1) and taper lock (A2).
or
A Fenner 5” B section pulley with two grooves (A3) and taper locks (A4).
In this case the maximum power which can be taken will be limited by the belts, and it will be necessary to
calculate for marginal applications.
Caution: Additional inertia must not be added to the P.T.O. shaft without specialist advice. Consult your
distributor if you need advice about non-standard drive arrangements.
•
•
