Illustration 44 g06481410
Typical example
(13) NRS Differential pressure sensor
(14) NRS valve
(15) Injector 1 and injector 2 (Injector 3 and
injector 4 not shown)
(16) Crankshaft speed/timing sensor
(17) Engine oil pressure switch
(18) Fuel rail pressure sensor
54 M0092609-05
