Illustration 40 g06300327
Typical example
(20) DEF Injector
(21) DPF Differential pressure sensor
(22) Temperature sensor controller
connection with 3 probes across
aftertreatment
(A) DPF temperature probe
(B) DOC temperature probe
(C) SCR temperature probe
