Illustration 41 g06511813
Industrial engine equipped with a balancer
(23) DPF Differential pressure sensor
(24) DEF Injector
(25) Temperature sensor controller
connection with 3 probes across
aftertreatment
(A) DOC temperature probe
(B) DPF temperature probe
(C) SCR temperature probe
M0092609-05 51
Operation Section
Sensors and Electrical Components
