Perkins 904J-E36TA - Page 70

(Table 10, contd)
Inducement Time
First Occurrence
None 18 Hours 18 Hours 50 Percent torque
Shut down or idle
Until fault heals
Cycling the keyswitch
will give 20 minutes
of full power
The system must be fault free for 40 hours before the system will reset to zero. If the fault is intermittent, and returns within the 40 hours, then
the repeat inducement time will be triggered.
The override can only be used once.
Inducement Time
Repeat Occurrence
None None 108 Minutes 50 Percent torque
Shut down or idle
Until fault heals
Cycling the keyswitch
will give 20 minutes
of full power
Inducement None None None
Notification None Emission malfunction
lamp will be on solid
Emission malfunction
lamp will flash
Emission malfunction
lamp will flash
The stop lamp will
activate
Emission malfunction
lamp will flash
Contact your Perkins dealer or your Perkins Distributor at level 1 warning, do not let the fault develop.
World-Wide DEF Level Warnings
Two options are available but only one option will be
enabled.
• The low-level warning lamp will operate when DEF
level reaches the trigger point of below 20 percent.
• At Level 1 the low-level warning lamp in the DEF
gauge will illuminate and the emission malfunction
lamp will be on solid.
• At Level 2 the low-level warning lamp for the DEF
is active and the emission malfunction lamp will
flash.
• At Level 3 all level 2 warning lamps are active,
plus the stop lamp will become active. The engine
will shut down or will only operate at 1000 RPM.
Filling the DEF tank will remove the warning from the
system.
Table 11
World-Wide DEF Level Option 1
-
Normal operation Initial indication Level 1 Level 2 Level 3
Inducement Trigger Above 19 percent Below 19 percent Below 12.5 percent 0 Percent reading Empty tank
Inducement None None None Engine may be de-
rated by 25 percent
torque
The engine may be
derated by 50 percent
torque.
A shutdown or low
idle only will be en-
forced after 5
minutes.
Notification None Low-level lamp
illuminated
Low-level lamp
illuminated
Emission malfunction
lamp on solid
Low-level lamp
illuminated
Emission malfunction
lamp flashing
Low-level lamp
illuminated
Emission malfunction
lamp flashing
Stop lamp on solid
70 M0092609-05
Operation Section
Selective Catalytic Reduction Warning System
