12 User’s Handbook, TPD 1285E, Issue 2
3.152
Rear and right side of T3.1524 engine
14 Water outlet
15 Breather pipe
16 Induction manifold
17 Fuelled starting aid
18 Alternator
19 Lubricating oil sump
20 Drain plug for lubricating oil
21 Starter motor
22 Fuel Iift pump
23 Rear lift bracket
24 Rocker cover
